Evolution Powersports Maptuner ECU Power Package 2017-2021 Polaris RZR XP Turbo & Turbo S 168

SKU:
Current Stock:
Out of Stock
EVP tunes will transform your already fast Turbo into an absolute animal! Podium proven time and time again, we relentlessly test and push limits to ensure our riders get the horsepower gains, power at the wheel and performance they need! With our Maptuner Power Package, you no longer have to send in your ECU to get flashed! Maptuner allows you to flash your ECU through the vehicles diagnostic port. A large color, app driven, touchscreen makes tuning a snap. Also featuring datalogging, monitoring, and code read/reset function, it allows you to accurately view or record your engines vitals. With an available Plug-n-Play AFR module, you can monitor and log air fuel ratios in real time! You can also return your vehicle back to stock at any time. Charts below outline performance expectations, included components, and equipment requirements required where applicable. All options include a MapTuner Tuning Device and diagnostic cable. Maptuner is a Windows based application.

Stock Injector Flash Package

Includes: Power Flash Device, Diagnostic Port Cable & all Stage Tunes in table below

ECU
Flash Stage
HP Boost (LBS) Wastegate Crack Pressure (lbs) Fuel (Octane) Recommended Exhaust
Stock 168 14 5 91

Stock or Aftermarket

Stage 1 180
16
5
91

Stock or Aftermarket

Stage 2 184
17
5
91
Stock or Aftermarket
Stage 3R 190
18
6
93
Stock or Aftermarket
Stage 4R 204
19
6
95
Stock or Aftermarket

Big Injector Flash Package

Includes: Power Flash Device, Diagnostic Port Cable, (2) Flow Matched Injectors, & all Stage Tunes in table below

ECU Flash Stage HP Boost (LBS) Wastegate Crack Pressure (lbs) Fuel (Octane) Recommended Exhaust
Stage 5Ri 209
19
6
E85
Stock or Aftermarket


EVP has made more power on this model than any previous generation stock turbo - stock injector vehicle Our tunes not only improve boost, fuel, timing, rev limit and speed limit changes, we also help the cooling system issues by lowering the fan on temperature by 20 Deg F. This makes a huge difference in the average temperature the engine operates at and prevents run away coolant temps on hot days and high loads. Each tune is customized with fueling corrections for intakes, exhausts, etc. Polaris made many changes to both the fuel system and tuning of the Bosch ME17 ECU. The biggest change is the fuel system was changed from a return style, rising rate setup to an automotive type return less configuration. The new hardware includes a separate fuel pump controller which varies the pressure to the fuel rail based upon input from an inline fuel pressure sensor and programming. The controller accomplishes this by raising and lowering the voltage to the pump. When the vehicle is keyed on, the fuel pressure initially rises to approximately 70psi. Once the engine is started, the fuel pressure drops to 40 psi and stays there until the engine sees boost pressure. In boost, the controller raises the fuel pressure back to 70 psi. The system makes for a much better running and safer setup as compared with earlier models. Tune Features Massive wheel horsepower gains Rev limiters raised by 500 RPMS both high and low gears - custom rev limits upon request Speed limiters raised: High gear-15 MPH Low gear-10 MPH Reverse-9 MPH No piggyback fuel controllers to mess with Dramatically lowered coolant temperatures by manipulating the fan on/off temperatures (EVP was the first company to do this) Stage Tune Suffix Identifiers: R: The Turbo Wastegate Crack Pressure Must Be Adjusted for Higher Boost (see our video on the 'Additional Information' tab) Non R: Tunes do not require any wastegate adjustment.
